24V DC motor.
Backup battery (optional).
Soft start & soft stop.
Auto-close function can be set.
Auto-reverse when obstruction.
Easy to release when power supply failure.
Technical data
| Model | FBC120 | FBC180 | FBC200 | FBC220 |
| Motor | DC 24V 60W | DC 24V 80W | DC 24V 100W | DC 24V 120W |
| Lift force | 600N | 800N | 1000N | 1200N |
| Max.door size | 10M2 | 12M2 | 14M2 | 16M2 |
| Power supply | 110V or 220V | |||
| Opening speed | 5.77m/min | |||
| Remote control | Rolling code 433.92Mhz | |||
| Rail leN.mal) | 3.3m | 3.6m | ||
